      Leybold THERMOVAC TR 216

      THERMOVAC TR – Precise Vacuum Measurement with Passive Sensors

      The THERMOVAC TR sensors utilize the proven Pirani thermal conductivity principle, providing reliable and cost-effective solutions for vacuum measurements across a wide pressure range.

      • Measurement Range: 5 × 10⁻⁴ to 1000 mbar for versatile applications.
      • Filament Options: Available with tungsten or platinum filaments.
      • High-Quality Measurement Cell: Aluminum cell with tungsten filament for maximum stability.
      • Temperature Compensation: Optimized performance from 0 to +40 °C.
      • Cost-Effective: Affordable replacement cells that are easy to replace.
      • Constant Filament Temperature: Stable and precise measurement results.

      Typical Applications: General vacuum processes, research and development, laboratory applications, industrial processes, and process control.

      • Produktkatalog
      Previous product Next product
      ``

      Invalid password
      Enter

      Legal

      • AGBs
      • Imprint
      • Data Protection
      • Contact
      © 2026, Druschke GmbH Vakuumservice Powered by Shopify
      • Choosing a selection results in a full page refresh.
      • Opens in a new window.
      Product details:
      Article number
      15787
      Connection flange
      DN 16 ISO-KF
      Pressure range
      5.00 × 10⁻⁴ - 1000 mbar
      Units of measurement
      Measuring principle
      Connection cable
      Connection cable
      Measurement range / Display range
      Flange
      Output
      Filament
      Set point
      Switching points
      Connection flange
      Temperature
      Interface
      Connection type
      Function/Control
